800GE1 Conductivity transducer for conductivity measurement with ZEPACOND 800 electrode sensor
Transducers are designed to measure the specific electrical conductivity of solutions. The specific electrical conductivity is the reciprocal of the specific electrical resistance at the reference temperature expressed in Scm-1 or Sm-1.
The input signals of the transmitter are the state of the conductivity sensor, the state of the temperature sensor and, if necessary, the input signal of an auxiliary input (e.g. the output signal from a flow sensor). The corresponding signals of the communication interfaces and data or keypad commands are also to be considered as input signals. The output signals of the transmitter are the conductivity, temperature, and possibly also the sample flow rate data, the analog output signals and the output signals of the communication interfaces.
The transmitters are specified products within the meaning of Act No. 22/1997 Coll. and are covered by the EC-800000 declaration of conformity.
